    Midwest Fasteners Sureshot II and Talon LD CD Gun Exploded View Diagram
    ITEM QTY MIDWEST FASTENER PART# DESCRIPTION HANLON PART#

    1

    1ALT

    1

    1

    050-1002-36



    MALE CONTROL CONNECTOR (AS SHOWN FOR NEWER UNITS)

    CCHU-M
    2 1 060-3046-00 MALE WELD CONNECTOR LDCCM
    5, 6 1 050-1005-34

    REAR BODY CAP

    (Parts 3, 4 are replaced by this 1 part)

    		 050-1005-34
    5 1 050-1005-65 RIGHT GUN BODY HALF 050-1005-65
    6 1 060-3010-01 SILVER SHAFT SPRING 1540
    7 1 181-3029-19 10-32 X 5/8 SOCKET HEAD SCREW 181-3029-19
    8 1 181-3029-20 10-32 X 3/16 SET SCREW 181-3029-20
    9 1 060-3028-00 GUN SHAFT BLOCK 1564
    10 1 060-3029-00 GUN SHAFT 1561
    11 1 060-1004-01 PIG TAIL WELD CABLE 1562
    12 1 181-3029-05 10-32 X 1/2 PAN HEAD SCREW 181-3029-05
    13 1 181-1260-01 #10 LOCK WASHER 181-1260-01
    14 1 181-3029-20 10-32 X 3/16 SET SCREW 181-3029-20
    15 1 050-1003-94 SHAFT BEARING 1565
    16 1 101-0601-00 STANDARD FACEPLATE 1518
    17 2 181-3029-20 10-32 X 3/16 SET SCREW 181-3029-20
    28 3 181-3029-18 8-32 X 3/4 SOCKET HEAD SCREW 181-3029-18
    19 1 060-3221-00 SHAFT BOOT 2000
    20 2 101-0801-01 WELD CABLE LEG CDL
    21 1 060-3222-07 BOOT RETAINER 70024
    22 1 060-3222-06 BOOT RETAINER SPLIT RING 70025
    23 1 101-0701-00 WELD GUN FOOT CDF
    24 2 181-1260-39 #10 FLAT WASHER 181-1260-39
    25 2 181-3029-19 10-32 X 5/8 SOCKET HEAD SCREW 181-3029-19
    26 1 050-1005-48 16-2 CONTROL CABLE 1229
    27 1 050-1005-70 RUBBER CABLE SLEEVE SMALL 050-1005-70
    28 1 050-1005-71 #4 WELD CABLE 1583
    29 1 050-1005-55 RUBBER CABLE SLEEVE LARGE 050-1005-55
    30 1 060-3311-46 WELD CABLE LUG CL410
    31 1 060-3053-00 TRIGGER MICRO SWITCH 1592
    32 1 050-1005-66 LEFT GUN BODY HALF 050-1005-66
    33 1 060-3003-00 TRIGGER BUTTON SPRING 1516
    34 1 050-1005-35 TRIGGER BUTTON 050-1005-35
    NOT SHOWN
    060-3010-04 SHAFT SPRING COPPER 1540-3
    060-3010-02 SHAFT SPRING GOLD 1540-2
    060-3010-03 SHAFT SPRING BLACK 1540-1
    060-3010-05 SHAFT SPRING RED 1540-4
